Zoom75 Pre-order

Batch 1

Go to:  Batch 2 | Batch 3 OCT 23 Batch

Pre-order Info    AT A GLANCE    PRODUCTS    KEYCAPS    MODULES    Specs    Features    Videos

Zoom75 Batch 1 pre-order closed!

Please visit the Updates page for status updates until delivery

Zoom75 limited pre-order is now open!

We have multiple batches of limited pre-orders open.

You can view the other batches through the links above

  • Pre-order Info

  • Import Methods

  • Pre-order Policies

Zoom75 comes with everything you need to build your keyboard, except for keycaps and switches.


Pre-order ends at 11:59 PM PST on April 26, 2023

Depending on our workload volume at the time of fulfillment, we may choose to use a third party fulfillment service to deliver the Zoom75 you for a quicker delivery time. Please do not order any product not on this page with your Zoom75 as the fulfillment service will not have them in hand

Canadian customers - please do not choose Xpresspost as a shipping method. Each Zoom75 (with the exception of Wired Edition) comes with a battery packed inside but not installed in kit. Canada Post does not allow such items to be shipped using Xpresspost

Zoom75 will be imported from China into Canada via two separate shipping methods:

Ocean Freight

Arrives to Canada via a ship. Takes 45-70 days in transit. This is the standard import method used in most keyboard / deskmat group buys. It's much cheaper than Air Express but takes much longer to arrive.


All units ordered via Ocean Freight are scheduled to ship out of Meletrix around July, 2023 and should arrive at Mech.land around late September, early October, 2023.

Air Express

Arrives to Canada via a cargo airplane, takes 7-15 days in transit. This import method is very expensive, as such some of the items brought over via Air Express have a markup added to cover the extra expenses


All units ordered via Air Express are scheduled to ship out of Meletrix around July, 2023 and are expected to arrive to us late July / early August.

IMPORTANT

You cannot combine Ocean Freight and Air Express items in the same order. Each individual order has to contain either all Ocean Freight or all Air Express items. This is because they arrive at different times


Please keep in mind the ETA is just our best guess according to the information currently available to us. Unexpected issues and delays can happen at every stage of the process.


Combinations

You cannot add any in-stock items to your order as we cannot guarantee its availability when the group buy is ready to ship.


You cannot combine this group buy order with a previous order as we cannot hold on to an order until the other one arrives.

Modifications

You may modify your order until the group buy ends on April 26, 2023

Please send an email to help@mech.land from the email address associated with your order and list the changes you'd like to see made.

Cancellations

You may cancel your order and get a refund until the group buy ends on April 26, 2023


Please keep in mind we will deduct 4% of the total from the refund as we do not get the transaction fees back from our payment processor.

Updates

Any status updates pertaining to this group buy will be posted in the status updates page.

Please follow the instructions on the contact us page if you need to change your address before the group buy ships.

Pre-order Batches

1️⃣ Batch 1 (You are here)

The first, unlimited pre-order of Zoom75 that took place between April 10 to April 26, 2023.


They're expected to ship out of China in July, 2023.


Air Express units are expected to arrive about 10 days after they leave China.


Ocean Freight units are expected to arrive to us 40-60 days after shipping, tentatively around mid September to early October, 2023

2️⃣ Batch 2

The second pre-order of Zoom75 that started on May 8, 2023 and will continue until sold out.


This is a rolling pre-order with limited quantities of a select few color/PCB variants.


These units will arrive with Batch 1 Ocean Freight units. They'll be fulfilled after all the Batch 1 Ocean Freight orders have gone out, tentatively around October, 2023.

3️⃣ Batch 3

This round of pre-order starts on July 1st, 2023 and continues until all units are sold out.


In addition to many Zoom75 color/PCB variants, there will be extra plates, internal weights, lots of LCD screens and other add-ons available.


These units are expected to leave China around late August / early September, 2023 and are expected to arrive to us via Ocean Freight sometime in November, 2023

Zoom75 At a Glance


15 EE colors

Essential Edition has 15 case colors with an Electrostatic coating with the exception of GT Silver, which has a nano coating.

4 SE colors

Special Edition colors have have an anodized or Eletrophoresis finish. They have an engraving at the blocker and an accent chamfer around the keys.

2 Wired Edition

Priced even lower than standard EE, there are two wired editions of Zoom75 sold in a pre-set color combo for those on a tight budget.

Zoom75 X Kitsune

A Zoom75 in collaboration with GMK Kitsune. Comes with engravings on the case, backplate and the external weight

Customizable modules

The top right 2u cluster can be customized with keys, badge, screen or a knob. EE, SE and Wired editions come with the knob module by default. All the other modules are sold separately.

Extra knobs & badges

Lots of extra badges and knobs are available for purchase provided you have the corresponding module. They come in many designs and materials. The knobs are compatible with Zoom65 V1 and V2

Backplates & weights

Another way to customize your Zoom75 to make it uniquely yours! Each Zoom75 comes with a backplate matched to the case and a weight color of your choice. Additional ones can be purchased separately.

Double-shot keycaps!

Five beautiful keycap sets matching Zoom75 colorways are also in pre-order. They're high quality double-shot PBT keycaps with the new WS mold.

Unlock more bonuses

All bonuses unlocked!


Every Zoom75 purchased in the pre-order will come with a USB Receiver Keycap, new 1u WS Keycap Puller and a Wuque Titanium Switch Puller

Essential Editions (EE)

Special Editions (SE)

Wired Editions & Collaborations

Add-ons & Accessories

Extra plates, PCBs, internal weight, storage bag, keyboard feet etc!

Customization Options

WS Double-shot Keycaps

Introducing: Modules!


The top right 2u cluster of the Zoom75 can be customized with one of four modules! These modules fit into the case and connect to the PCB using the included ribbon cable.

The knob module is included with every EE, SE and Wired Editions. Zoom75 x Kitsuni comes with a badge module. All the other modules are sold separately.

Knob Module

The knob module holds one 1u key and the knob. This is the default module with EE, SE and Wired Editions.

There are 14 different knob designs to choose from, including two sculpted designs. All the knobs are compatible with Zoom65 V1 & V2.

Badge Module

The badge module let's you display a badge in the 2u cluster. Default module included with Zoom75 x Kitsuni

Choose from 12 different designs of metal badges. The badge module does not include any badges, they must be purchased separately.

LCD Module

A nifty LCD screen that can display a whole host of useful information including notes, alerts, typing speed, internet speed or a static image.

Check out the video above to see a demo of what the LCD screen is capable of. This module is not included with any kit and must be purchased separately.

Two-key Module

For those who likes things simple and orthodox, there's a two-key module that adds two extra keys that are fully customizable by VIA.

Backplates & Weights


13 Backplate Colors

Each case comes with a specific backplate as indicated on the product page. Materials include glass, carbon fiber and stainless steel. You can purchase additional backplates to switch it up every now and then!

9 Weight Colors / Materials

Choose from any of the 9 color options for knob and external weight with every Zoom75. You can choose an aluminum weight, or go for a brass weight with a sleek PVD finish that adds a bit more heft to the setup! Additional weights can be purchased separately.

New Tri-Mode PCB

New default PCB for Essential Edition, Standard Edition and Zoom75 x Kitsune


Bluetooth, RF & Wired!

An all-in-one PCB! You can connect to your devices via Bluetooth 5.0, 2.4Ghz RF (USB receiver included) and in plain old wired mode. You can charge the battery with any USB-C cable, or simply use it in wired mode for a while!

Multi-layout

The new Tri-Mode PDCB is fully compatible with VIA, the powerful GUI widely renowned for it's customizability and ease of use. Remap any key on the keyboard on 4 different layers, including the knob. Use built in powerful shortcuts and macros, or define your own!

VIA customization

Every Zoom75 comes with two 2250 mAh Li-ion battery included in the kit. The battery should last 6-8 weeks between charges under normal use. Once it's out of charges simply connect your keyboard to your PC / laptop using the included USB-C cable.

Specs & Kit Contents


EE / SE Kit Contents

- Aluminum top and bottom case*

- Aluminum / SS external weight*

- Aluminum / PVD coated brass rotary knob matching the external weight

- Backplate matching the case unless otherwise specified

- Knob module kit (matches case color)

- 2x Flexible flat cable for module

- Hot-swap, multi-layout, Tri-mode / VIA PCB with per-key RGB with or without flex cuts*

- Daughterboard + JST cable

- 2.4Ghz receiver

- Polycarbonate plate

- Gasket sleeves

- Set of WS Stabilizers V3 (TPU)

- 2x Li-ion battery

- Coiled USB-C cable

- Silicone keyboard feet

- PORON Dampening kit
- Screws and other installation tools

- Storage case

* User customizable option in terms of functionality, color, material and/or finish.

Wired Edition Kit Contents

- White variant: White top & bottom case, E-white knob & weight, SS PVD Silver backplate.

- Black variant: Black top & bottom case, Anodized Black knob & weight, SS PVD Black backplate

- Knob module kit (matches case color)

- 2x Flexible flat cable for module

- Hot-swap, multi-layout, Wired / QMK / VIA PCB, NO RGB, without flex cuts.

- Daughterboard + JST cable

- Polycarbonate plate

- Gasket sleeves

- Set of WS Stabilizers V3 (TPU)

- Foam to cover up battery slot. No batteries included.

- Coiled USB-C cable

- Silicone keyboard feet

- PORON Dampening Kit
- Screws and other installation tools

- Storage case

x Kitsune Kit Contents

Same as EE / SE kit, with the following changes:

- Anodized Navy top & bottom case, external weight.

- Glass Rose Gold backplate

- Badge module kit

- Knob module kit (matches case color, knob not included)

- Kitsune badge

Specifications

- Gasket mount design

- 75% layout

- 1.2mm PCB with Ai03 Universal DB

- Default plate: Polycarbonate

- 5° Typing angle

- 22mm front height

- Case dimension is 323.6 x 145.8 x 34.7mm or 12.74 x 5.74 x 1.37 inches.

- Finish treatment: Electrostatic coated, anodized, electrophoresis and nano cated, depending on edition and color.

- Default Tri-mode PCB in EE, SE & Kitsune can be used in wired, Bluetooth or RF mode with the USB receiver.

- Tri-mode PCB supports VIA and not QMK, wired PCB supports QMK but not VIA.

- Tri-mode PCB BT polling rate: 125hz

- Tri-mode PCB 2.4GHz polling rate: 1000hz

- Tri-mode PCB wired mode & wired PCB polling rate: 1000hz

- Essential kit with Alu knob / weight / Glass Mirror Back Plate: 1.74 kg

- Essential kit with brass knob / PVD SS weight / Glass Mirror Back Plate: 2.03kg

- Essential kit with Alu knob / weight /PVD Back Plate: 1.87 kg

- Essential kit with brass knob / PVD SS weight / PVD Back Plate: 2.15 kg

Internal stainless steel weight (sold separately) weight: 358g.

The Screen Module is NOT COMPATIBLE with the wired edition as it requires Bluetooth to function.

Other Features


Gasket mount

Zoom75 uses a gasket isolation mount structure for a soft, bouncy and pleasant typefeel that won't fatigue your fingers even after hours of typing. Gasket mount keyboards sound better and feel more even throughout the board than the typical off-the-rack tray mount keyboards.

Multi-layout

Unlike traditional keyboards, you are not stuck with just one layout on Zoo75! Change things up every now and then with split backspace, left shift and spacebar! You can also switch between normal and stepped caps lock or ANSI.

Per-key RGB

Both the Tri-Mode PCB and Wired PCB support per-key RGB lighting. You can choose from provides a wide range of colors and effects for a different visual experience. Can be used in both wired and wireless mode.

Hot-swap Switches

Both wired and Tri-Mode Zoom75 PCBs feature Kailh Hot Swap sockets that allow you to just push the switches on, no soldering required! Changing switches is a breeze, you can go from linear to tactile in a matter of minutes, all on the same keyboard!

Gasket Sleeves

The gasket sleeves are made of supercritical foam, it can stabilize the plate as the same time giving appropriate space allowing it to flex in a balanced way. Just the right softness, not too stiff, not too much flex.

Plate variety

Plates in other materials, such as brass, aluminum and FR4, can be sold as add-on accessories, and they dramatically change the feel and sound of the keyboard

WS Stabilizers V3

The new stabilizers were under development for almost one year, and will be included with the Zoom75. They use soft TPU around the wires to achieve better performance even with minimal lubing.

Foam included

In order to reduce resonance, many tests were done on the foaming material of the Zoom75. Meletrix made the new PORON lighter and denser, as a result they make the keyboard sound more concentrated and deeper than stock settings.

Optional Internal Weight

Take your keyboard to the next level with an internal SS weight, sold separately. It weighs about 358 grams.
